GE FANUC IC693ALG392 SINGLE-ENDED OUTPUT CHANNELS PROVIDING 0 TO +10 VOLTS
Technical Specifications for IC693ALG392
Brand GE Fanuc
Series Series 90-30
Part Number IC693ALG392
Resolution at -10 to 10 V 0.312 mV
Product Lifecycle Status* Discontinued/Obsolete
Product Description Analog Current/Voltage Output
No of Channels 8
Current Range 4 to 20 mA, 0 to 20 mA
Voltage Range 0 to 10 V, -10 to 10 V
External Supply Voltage Range 20 to 30 VDC
Internal Supply Voltage 5 VDC from PLC backplane
Update Rate 8 ms all channels
Resolution at 4-20 mA 0.5 microamps
Resolution at 0-20 mA 0.625 microamps
Resolution at 0-10 V 0.312 mV
Internal Power Consumption 110 mA at 5 VDC, 315 mA at 24 VDC User Supplied
About IC693ALG392
The IC693ALG392 is a Series 90-30 module. This module is an analog output module that is typically used for implementing modulating control of instruments or devices such as Variable Frequency Drives (VFD), Control Valves, Positioners, converters and other similar modulating devices. It may also be used to re-transmit analog data to receiving elements such as recorders, data loggers and other compatible receiving devices.
The IC693ALG392 features Eight (8) output channels with configurable resolution of 15 or 16 bits, depending on the analog output range selected. It is capable of providing voltage signals such as 0 to +10 volts (unipolar) / -10 to +10 volts (bipolar) voltage and 0 to 20 milliamps / 4 to 20 milliamps output signals. In able to generate the output analog signals, this module requires an isolated 24VDC power, directly connected to the designated terminal block of the module.
This module is factory calibrated. Calibration information includes .625 µA for 0 to 20 mA; 0.5 µA for 4 to 20 mA; and .3125 mV for voltage (per count). Each channel of the module exhibits an update rate of Eight (8) milliseconds with resolution of 0.5 µA (1 LSB = 0.5 µA) for 4-20 mA; 0.625 µA (1 LSB = 0.625 µA) for 0-20 mA; 0.3125 mV (1 LSB = 0.3125 mV) for 0-10VDC and 0.3125 mV (1 LSB = 0.3125 mV) for -10 to +10VDC outputs signals.
This module is fitted to any slot of the RX3i chassis. There are no limits to the number of instances allowed per an RX3i rack. The number of instances depend on the number of Analog data a specific RX3i controller supports.
Introduction of Wisdomlong Technology CO.,LTD
The company with domestic and international numerous well-known brands supplier to build have extremely good relations of cooperation, in Japan, South Korea, southeast Asia, Africa, Europe and the United States, and formed a stable and efficient supply network. The agent and the products are widely used in machinery, equipment manufacturing, electric power, metallurgy, petrochemical, automobile manufacturing industry, paper making, chemical industry, medicine and aerospace industries.
OTHER SUPERIOR PRODUCTS of Wisdomlong Technology CO.,LTD
| Yasakawa Motor, Driver SG- |
| Mitsubishi Motor HC-,HA- |
| Westinghouse Modules 1C-,5X- |
| Emerson VE-,KJ- |
| Honeywell TC-,TK- |
| GE Modules IC - |
| Yokogawa transmitter EJA- |
Our brands of Wisdomlong Technology CO.,LTD
Terms
1. We ships worldwide and accepts T/T and Paypal.
2. All items are subject to availability and passing our QA testing and inspection.
3. Turnaround Time:
Standard order processing is 1-2 business days plus shipping method chosen.
Rush and off-hours service available for an additional fee.
4. Packaging and Handling:
Items are safely packaged in custom shipping cartons for protection.
Shipping
1. We ship worldwid use UPS, FedEx, DHL, or Truck when needed.
2. Call to use a shipping service other than the ones listed.
3. International Customers are responsible for all Customs fees, VAT, and other fees applied by their respective countries.
FAQ
1. Why choose us?
* Passionate, experienced and highly-educated R & D and sales team;
* Reasonable price and reliable products, skillful and careful assembly;
* Strict quality assurance and quick aftersales service;
* Lifetime technical support, can come with customized setting.
2. How about your product warranty?
* We offer one-year warranty upon delivery.
3. How about the aftersales support?
* We will offer on-time response for online enquiries from oversea users. Please feel free contact us by email, WhatsApp, WeChat and SKYPE.
Conact Person:
Lumi
Phone:+86-14775061220
WhatsApp:+86-14775061220
Wechat:forever_12-20_
Tel: +86-755-25020661
Fax: +86-755-25020662
WISDOMLONG TECHNOLOGY CO.,LIMITED
Email: weitianlong23e@163.com
Address: 23E BlockB,Lushan Building,Chunfeng Road,Luohu District,Shenzhen,518001,China
|
|
GE FANUC IC693ALG392 SINGLE-ENDED OUTPUT CHANNELS PROVIDING 0 TO +10 VOLTS Images
|
