TC-OAH061 Analog Ouput 6pt Mod (4-20MA) CIOM-A
TC-OAV061 Analog Output Module 6 pt (10V), CIOM-A
TC-OAV081 AO Module 8pt (4-20ma & 10V), CIOM-A
TC-ODA161 AC Output Module 120/220vac 16pt, CIOM-A
TC-ODD321 DC Output Module 24vdc 32 pt, CIOM-A
TC-ODJ161 DC Output Module 24vdc 16pt, CIOM-A
TC-ODK161 AC Output Module 120/220vac 16pt, CIOM-A
TC-PCIC01 ControlNet Interface Card (PCI Bus)
TC-PCIC02 ControlNet Interface Module, PCI bus
TC-RPCXX1 120/240 VAC Redundant Power Supply
TC-TBCH Field Wiring Connector 36 pos
TC-TBNH Field Wiring Connector 20 pos
TK-CCR014 CNI, Redundant Media, Coated (TK-CCR013)
TK-FPDXX2 Conformal coated 24VDC Pwr Supply
TK-FXX132 13 slot chassis, coated, 13 amp
TK-IAH161 AI 16 Module, CIOM-A, Coated
TK-IDD321 DC Input 24vdc 32pt, CIOM-A, Coated
TK-IXL061 Thermocouple Input 6pt, CIOM-A, Coated
TK-IXR061 RTD Input 6pt, Coated
TK-OAV081 Analog Output 8pt, CIOM-A, Coated
TK-ODD321 DC Output 24vdc 32 pt, Coated
TP-DIKBTA-100 IKB Keyboard w/Trackball, Desktop
TP-DOKBNA-100 OEP KYBD DESKSIDE GUS
TP-LCNECM-100 XLCN EXTENDER SET CE MULTIMODE
TP-LCNP02-100 LCNP4M Interface Card, Mid-siz
TP-OPADP1-200 OEP Adapter, 240V, Deskside IKB
TP-OPADP1-201 OEP ADAPTER FOR DESK, WKS2, 24
TP-ZSBHM2-100 UPG KIT, HM TO SBHM W/TWO DRIVES
Chassis Input/Output Modules-Series A (CIOM-A) is a chassis based platform. Modules exist in a single-wide and double-wide form factor. Modules are inserted into chassis slot positions; single-wide occupy one slot position while double-wide modules occupy two slots. As a platform, the chassis is host to not only I/O modules, but modules that perform other functions.
Some examples include:
I.C200E Control Processor
II.Redundancy Module (RM)
III.Battery Extension Module
IV.ControlNet Interface Module (CNI)
V.Ethernet Module
The I/O modules are the focus of this document. Other module types are covered in separate Specification documents.
Model Number Conventions (TC and TK)
All model numbers are preceded by a TC- or a TK-. The TC designator indicates that the module is not conformal coated while the TK designator indicates that the module has conformal coating applied. Aside from this the modules are identical.
